优质100kv电线杆优质钢制电线杆低价国产-配电设备
  • name
  • name
  • name
  • name
  • name
  • name

优质100kv电线杆优质钢制电线杆低价国产-配电设备

MOQ: 10 tonnes
Price: US$1,150/tonnes 10-99 tonnes
Details Information
Product Description
Detail Information
型号:
Support Customization
种类:
电力钢管塔
原产地:
Hebei, China
品牌:
Yinghao
高:
支持自定义
表面处理:
热浸镀锌, 热浸镀锌
吊装方法:
手动
材料:
Q420B/Q355B/Q235B, Q420B/Q355B/Q235B
产品名称:
电力钢管塔
应用程序:
电力
使用寿命:
20-50岁
Product Description
Product Description
优质100kv电线杆优质钢制电线杆低价国产-配电设备 0
The power tower is a steel structure frame that maintains a certain safe distance between the supporting wires and between the ground wire and the ground building in the transmission line. According to its shape, it is generally divided into five types: wine glass type power tower, cat head type power tower, upper font type power tower, dry font type and barrel type. According to its use, it is divided: tightening power tower, linear power tower, corner power tower, transposition power tower (replacement of conductor phase position tower), terminal power tower and crossing power tower, etc.
Height
Section No.
Pole Shape
Diameter(mm)
Thickness(mm)
Material Type
Surface Treatment
25FT
1
octagonal
120/152
2.75
ASTM A572 GR50/Q345
hot dip galvanized
30FT
1
octagonal
127/226
3
ASTM A572 GR50/Q345
hot dip galvanized
35FT
1
octagonal
127/248
3
ASTM A572 GR50/Q345
hot dip galvanized
40FT
2
octagonal
127/317
4
ASTM A572 GR50/Q345
hot dip galvanized
45FT
2
octagonal
127/328
4
ASTM A572 GR50/Q345
hot dip galvanized
50FT
2
dodecagonal/12sides
127/340
4
ASTM A572 GR50/Q345
hot dip galvanized
55FT
2
dodecagonal/12sides
162/468
4
ASTM A572 GR50/Q345
hot dip galvanized
60FT
2
dodecagonal/12sides
153/468
4
ASTM A572 GR50/Q345
hot dip galvanized
65FT
2
dodecagonal/12sides
127/510
4
ASTM A572 GR50/Q345
hot dip galvanized
70FT
2
dodecagonal/12sides
200/468
5
ASTM A572 GR50/Q345
hot dip galvanized
75FT
2
dodecagonal/12sides
200/478
5
ASTM A572 GR50/Q345
hot dip galvanized
80FT
3
hexadecagonal/16sides
190/540
5
ASTM A572 GR50/Q345
hot dip galvanized
85FT
3
hexadecagonal/16sides
223/582
5
ASTM A572 GR50/Q345
hot dip galvanized
90FT
3
hexadecagonal/16sides
223/582
5
ASTM A572 GR50/Q345
hot dip galvanized
95FT
3
dodecagonal/12sides
260/650
5
ASTM A572 GR50/Q345
hot dip galvanized
优质100kv电线杆优质钢制电线杆低价国产-配电设备 1


STEEL ELECTRIC TRANSMISSION POLE

Steel electric transmission poles are commonly used in electrical power distribution systems, particularly in areas where
underground cable installation is not feasible or cost-effective. These poles are strategically placed along transmission lines to
provide the necessary support for the conductors that carry electricity from power plants to substations and ultimately to homes,
businesses, and industries.
The design of steel electric transmission poles can vary based on factors such as the voltage of the power lines, the terrain of
the installation site, and local building codes and regulations.

GENERAL SPECIFICATIONS

* Height : 9 - 30M
* Pole Sections : 1 - 3 * Length of per Section: within 11.8m once forming without slip joint
* Material : ASTM Standard Steel Grade (Q235B, Q345B, Q355B GR65 etc)
* Pole Thickness : 2.75MM - 16MM
* Maximum Load : Up to 1800 kg
* Connection Method : Direct Embedment
* Embedment Depth : Up to 2000MM
优质100kv电线杆优质钢制电线杆低价国产-配电设备 2




STRONG CORROSION RESISTANCE


The Corrosion Resistance Of steel Pipes, The Service lifeCan Be Extended, And it is Suitabie For Various Harsh Environmental Conditions.



SMALL FOOTPRINT

About 1/3 Of A Self-Standing Tower, which Reduces landAcquisition Costs And construction Difficulty, lt ls Especially Suitable For Areas With limited land Resources Such AsCities And Mountainous Areas
优质100kv电线杆优质钢制电线杆低价国产-配电设备 3
优质100kv电线杆优质钢制电线杆低价国产-配电设备 4



SHORT CONSTRUCTION PERIOD

The construction speed ls Fast And The Power QutageTime ls Short, which Can Reduce The Impact Of ElectricityConsumption On Surrounding Residents And Businesses




EXCELLENT PERFORMANCE


Steel Pipe Poles Have Higher Safety And Stability, LowerMaintenance Costs, And Better Aesthetics In Power Systems
优质100kv电线杆优质钢制电线杆低价国产-配电设备 5
Specification
item
value
Model Number
Support customization
Type
Electric power steel pipe tower
Brand Name
Yinghao
Place of Origin
China
Hebei
Height
Support customization
Surface Treatment
hot dip galvanizing
Lifting method
Manual
Material
Q420B/Q355B/Q235B
Material
Q420B/Q355B/Q235B
Product name
Electric power steel pipe tower
Application
Electricity
Surface treatment
Hot Dip Galvanized
Service life
20-50 Years
Company Profile
优质100kv电线杆优质钢制电线杆低价国产-配电设备 6
优质100kv电线杆优质钢制电线杆低价国产-配电设备 7
优质100kv电线杆优质钢制电线杆低价国产-配电设备 8
FAQ
1. who are we?
We are based in Hebei, China, start from 2013,sell to Africa(20.00%),North America(10.00%),Eastern Europe(10.00%),Central America(10.00%),Northern Europe(10.00%),South Asia(10.00%),Domestic Market(10.00%),South America(5.00%),Southeast Asia(5.00%),Mid East(5.00%),Eastern Asia(5.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Lightning tower,Electric power steel pipe tower,Electric angle steel tower,Wind power early anemometer tower,radio and television tower

4. why should you buy from us not from other suppliers?
Our company has advanced production equipment and excellent company team. The company's integrity and practicality, service follow-up, and product quality assurance have been praised and recognized by the industry.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
